3T DUMPER

Mecalac TA3 3T Dumper: Versatile & Robust Material Movement for Modern Sites

The Mecalac TA3 3T Dumper is a high-performing hydrostatic site dumper built to deliver efficiency and reliability in diverse construction environments. With its 3-tonne payload capacity and choice of skip configurations, it provides a flexible solution for transporting aggregates, spoil, and various materials quickly and safely across challenging terrains.

Features

• 3-Tonne Payload Capacity: Capable of handling significant loads up to 3000 kg (3 tonnes) with a heaped skip capacity typically around 1.95 m³ (2.55 yd³). This substantial capacity makes it ideal for managing larger volumes of material, reducing the number of trips required.
• Powerful & Compliant Engine: Powered by a reliable and fuel-efficient Kubota D1703M 3-cylinder diesel engine, typically delivering 18.5 kW (25 hp). This engine meets the latest EU Stage V emissions regulations, ensuring compliance with stringent environmental standards and lower emissions.
• Hydrostatic Transmission with Permanent 4x4: Features an advanced hydrostatic transmission that provides smooth, stepless power delivery and excellent control. Coupled with permanent 4-wheel drive, it ensures superior traction and stability across demanding, uneven, and wet terrains, enhancing safety and productivity. Max travel speed is around 14.8 km/h (9.2 mph).
• Skip Versatility: The TA3 range typically offers choice between:
  • Front Tip Skip (TA3H): For bulk material movement and straightforward dumping.
  • 180-Degree Power Swivel Skip (TA3SH): A highly popular option allowing the skip to rotate 180 degrees, enabling precision placement of loads to either side of the machine without needing to reposition the entire dumper. This is invaluable in confined spaces or when backfilling trenches.
• Robust & Rental-Tough Design: Built for extreme durability, with a strong articulated chassis and heavy-duty skip construction. Designed to withstand the rigours of continuous site work and the demands of the rental market.
• Advanced Safety Features: Mecalac prioritises operator safety, integrating features such as:
  • ROPS Foldable Bar: A Roll-Over Protective Structure (ROPS) is standard, providing critical operator protection in the event of a roll-over. The foldable design also aids in transport and storage.
  • Operator Presence System: Often includes systems that require the operator to be seated with a lap belt engaged for machine operation.
  • Heavy-Duty Locking Device: Keeps the skip facing forward when on the move, enhancing stability and safety.
  • Hazard Detection and Start/Stop Control (on newer models): Advanced telematics and safety features for improved site management and fuel efficiency.
  • Hi-Vis Features: High-visibility steps and grab handles for safe access and egress.
  • Reverse Alarm and Amber/Green Beacons: For increased site awareness.
• Excellent Manoeuvrability: Despite its 3-tonne capacity, the TA3 is designed for agility. Its articulated chassis provides excellent turning capability, and the compact overall dimensions (width typically around 1.85m to 1.95m) allow it to operate effectively in restricted areas.
• Operator Comfort & User-Friendly Controls: The operator environment is designed for ease of use and comfort, featuring simple, intuitive controls that help operators adapt quickly. A comfortable seat reduces fatigue over long shifts.
• Easy Serviceability: Designed with accessibility in mind to simplify routine maintenance and reduce downtime.

Applications

The Mecalac TA3 3T Dumper is a popular choice across a wide range of construction and landscaping applications:

• House Building & Residential Construction: Moving soil, rubble, sand, and aggregates on confined building plots.
• Landscaping & Groundworks: Transporting topsoil, decorative aggregates, and waste for large garden projects, sports fields, and public spaces.
• Civil Engineering: Efficiently moving materials on roads, utility installations, and drainage projects.
• General Construction Sites: Versatile for transporting materials around site, especially in tight spaces or between different levels.
• Demolition & Site Clearance: Clearing debris and waste from demolition areas.
• Tool Hire Fleets: Its robust construction, reliability, and emphasis on safety make it a staple in rental yards.
